AMR Robot

Your Professional AMR Robot Supplier

Our goal is to become your true partner in the field of AMR Robot in China. The factory has accumulated rich manufacturing experience, our company is committed to applying advanced manufacturing technology and strict quality control standards to each product, the company has dozens of machining centers, CNC lathes, milling machines and other equipment, the use of three-coordinate equipment for strict quality management, and full-time quality control personnel, to provide high-quality AGV and accessories products for domestic and foreign customers, and to provide customers with customized products and services. The price is competitive, the product quality is guaranteed, and it is a good choice for your long-term cooperation.

Why Choose Us

Our services

We provide comprehensive after-sales service, telephone response within 24 hours, and 3-5 days of national on-site technical support.

Our production market

Mindong products have been exported to overseas markets such as southeast asia, north america, and europe.

Our equipment

We have dozens of machining centers, cnc lathes, milling machines and other equipment, providing high-quality agv and accessories products for domestic and foreign customers, and can provide customized products and services for customers.

OEM

We can design and produce according to customer requirements and specifications, and we also have certain independent design capabilities. We can provide innovative design solutions according to customer needs and market trends to achieve product uniqueness and differentiation.

Laser Slam Amr With HMI
The MDAMR-SL-H series robot is a smart handling robot that integrates intelligent navigation, autonomous obstacle avoidance, efficient transportation, and automatic charging for intelligent...
read more
Slam AMR
Slam amr is an autonomous mobile robot that, in contrast to AGV, do not need to lay magnetic strips or tracks, but instead rely on advanced navigation technology to move around.Slam amr use laser...
read more
AMR Robot Warehouse
The AMR robot warehouse combines advanced laser autonomous navigation technology, laser sensor technology and automation control technology to enable the amr robot warehouse to autonomously...
read more
AMR Mobile Robot
With the rapid development of science and technology, automation and intelligence has become an important force to promote the transformation and upgrading of enterprises, amr mobile robot as a...
read more
AGV AMR Robot
In the manufacturing industry, AGV is used in material handling on the production line, which can reduce the labour intensity of manual handling and improve the material handling efficiency. In...
read more

Advantages of AMR Robot

Quick installation & adaptability

Amrs are good because they can be set up fast. Unlike other machines that need big changes to the place, amrs fit into the warehouse without much trouble. This helps save time when setting up or making changes.

Safety

Safety is important in a warehouse, and amrs make sure to be safe. They move at a steady speed, avoid things in their way, and follow safety rules. This makes sure accidents are less likely, keeping both the robots and people safe.

Removal of repetitive tasks

Amrs do jobs that repeat a lot. This helps human workers because they get more time to do interesting work instead of the same thing over and over. It makes work more enjoyable.

Consistent performance

Amrs work very precisely. They do tasks the same way every time and don’t make mistakes like tired humans might. This helps get orders right and reduces errors.

Collaborative work (cobots)

Amrs work well with people. They look friendly and do simple jobs, letting people focus on harder tasks. It’s like they’re good buddies helping each other out.

Cost optimization & staffing efficiency

Amrs save money. They bring things directly to human workers, so workers don’t have to walk around so much. This helps keep costs steady, unlike paying more when people work more.

Applications of AMR Robot

Picking & packing

Amrs speed up how orders are put together. They move fast, picking up the right items without mistakes. This means your customers get what they ordered sooner, and you deal with fewer wrong orders.

Inventory management

Amrs help you stay on top of what you have in stock. They scan items and update your inventory in real time. Knowing exactly what's in stock means you won't order too much or run out of something you need.

Material transportation

Whether it's delivering materials to where your products are made or taking finished goods to storage, amrs handle the heavy lifting. They can carry big loads, making sure everything gets to the right place quickly. This keeps your operations moving fast and saves your team from doing the heavy lifting.

Inspection & monitoring

In places where quality can't be compromised, amrs keep an eye on things. They check on products and conditions around the clock, letting you know if something's not right. Catching issues early keeps your operations smooth and ensures what you produce meets your high standards.

Product parameters

Dimension	Dimension	800*590(mm)
	Net weight	70kg
	Max loading weight	200kg
	Total power	100w
	Appearance material	Fireproof cold rolled sheet
Sensor	LiDAR*1	Detection range: 230º
		Detection distance: 0.05~25m
		Sampling frequency: 4500Hz
		Scan speed: 10Hz
	Depth camera*2	Position: Front (default), top (optional)
		FOV:H 58.4° V 45.5°
		Output: RGB+D
		Detection distance: 0.4~2m
	Ultrasonic (optional)	Position: Back
		Detection range: 15º
		Detection distance: 0.1~0.5m
	Screen	7-inch LCD screen, resolution 1024*600, with multi-touch function
	IMU	6DOF; rate dynamic range: ±2000dps; accuracy: 0.01 degrees
Environment	Operating environment	Indoor, clean environment, no corrosive gases
	Operating temperature	Minus 0ºC~55ºC; anti-UV; anti-corrosion
	Storage temperature	Minus 10ºC~65ºC
	Charging temperature	5~40ºC(indoor)
Sports performance	Travel speed	0.3-1m/s adjustable
	Narrow passage	90cm
	Climbing angle	10º
	Overpass width	≤5cm
	Overslope height	1cm
Telecommunication	4G	Supported, 4G transformation accessories need to be installed
	5G	Supported, 5G transformation accessories need to be installed
	WIFI	Wifi module (AP6256) 2.4G&5GHz, supports 802.11a/b/g/n/ac protocol
Regulatory system	Planning model	Autonomous obstacle avoidance
		Track running
		Passing point
Charging & battery life	Battery	Charging voltage: 43.2V
		Capacity: 38.4V 25Ah
		Battery material: lithium iron phosphate battery. The decomposition temperature of lithium iron phosphate is about 600°C. The high temperature resistance of lithium iron phosphate can reach an electric Heating peak of 350°C-500°C.
		Battery life: 10-15 hours Deploying charging piles can achieve 7*24h service
		Standby time: 30 hours
		Charging method: Automatically recharge when low battery. You can also manually send back the pile command
		Time required for full charge: 5.5 hours
		Battery life: More than 2000 complete charge and discharge cycles
	Adapter	Working voltage: 100~240VAC, 50/60Hz
	Charging pile	Size: 375mm160mm355mm
		Weight: 4.35kg
		Input: 100-240V~50/60 Hz
		Output: 43.2V==5.0A
Maping	Maping	Incremental mapping: Supported
		Cloud mapping: Up to 10,000 square meters
		Scanning range: 360°
	Map editing	Coordinate points
		Charging pile
		Virtual wall
		Elevator area
Elevator system	Elevator management system	Elevator Management: Management Platform
	Ladder control equipment	Communication	4G
User interface	Hardware interface	Thernet	Rj45
		WIFI	2.4G/5G
		Audio	3.5mm Headphone plug
		Power interface	DC 24V 16A
			DC 12V 10A
			DC 5V 2A
Power management	Battery information		Support
Wheel	Number of main hubs	2
	Hub motor size	5.5 inch
	Motor voltage	24V
	Universal wheel	4
	Guide wheel	2
	Suspension	Swing bar active suspension
	Housing ground clearance	50mm
	Noise	≤50dB
Other	Emergency stop button	It is placed on the chassis and can be triggered by pressing the red button;
	Switch	Ship type power switch; on/off key
Platform	Remote monitoring platform	Real-time status monitoring of robots;
	Real-time data visualization large screen	Display the real-time status and operational statistical analysis of robots under different businesses

Packaging & Delivery

Package Size

Package Gross Weight

Lead Time

106.00cm * 69.00cm * 49.00cm

105.000kg

15 days (1 - 1 Pieces)

To be negotiated ( > 1 Pieces)

package

productcate-1-1

Payment & Delivery

productcate-1-1

FAQ

Q: Our country's power supply and plug are different, how do you solve it?

A: We effortlessly accommodate your country's unique power specifications by providing tailor-made transformers and plugs to match your local standards. This ensures that the AMR Robot performs seamlessly, regardless of the environment.

Q: Payment methods?

A: We offer a diverse array of convenient payment methods, including T/T, M/G, L/C, D/P, and more, designed to suit your financial preferences with unmatched flexibility and convenience.

Q: Packing method?

A: Our products are carefully encased in high-grade export wooden boxes, providing optimal protection and security throughout their journey to your location.

Q: Main export market?

A: Our esteemed range of products is globally recognized, with a thriving export market extending across North America, Europe, Southeast Asia, South America, and beyond.

Q: How to ensure the customer standard use the instrument?

A: We simplify the installation and operation of our products with comprehensive, easy-to-follow instructional videos. Additionally, we can arrange for our expert engineers to provide on-site training for equipment operation, facilitating a smooth transition and integration.

Q: Whether you could make our brand on your products?

A: Certainly, we are pleased to offer brand customization by adorning our products and packaging with your logo, provided your order meets our minimum order quantity (MOQ).

Q: Whether you could make your products by our color?

A: Absolutely, we can tailor the color of our products to resonate with your brand's identity, as long as your order satisfies our minimum order quantity (MOQ).

As one of the leading AMR robot manufacturers and suppliers in China, we warmly welcome you to wholesale high quality AMR robot made in China here from our factory. For customized service, contact us now.
